1/2" 1-Piece Ball Valve
In stock
SKU
BV050-SS-1
Size | 1/2" |
---|---|
Material | Stainless Steel 316 |
Handles | Stainless Steel 304 |
Part Number | BV050-SS-1 |
Temperature Rating | -4°F to 302°F |
Thread | 1/2" Female NP |
Working Pressure | 1000 PSI |
Seal | Teflon (PTFE) |
$10.71
1/2" Threaded, Reduced Port, One-Piece (1000 PSI)
CLICK HERE for All Sizes
CLICK HERE for Full Port
This robust 1/2 inch one piece ball valve with 1/2” female NPT thread on either end for easy connection. It is manufactured using high grade 304 stainless steel. It is a full port design, rated at 1000 PSI, and WOG ready (Water, Oil, Gas). It is Designed to control flow on a 1/2” pipe line with a simple “on” and “off” 90 degree turn of the handle. Handles can be locked in the open or closed position using a latch lock.
- Product description:
- ● 1/2” Female NPT Threaded, One Piece, Reduced Port Ball Valve
- Uses:
- ● Used to control flow with a "on/off" action.
- Port (Bore):
- ● Reduced Port.
- Thread:
- ● 1/2” Female NPT Threads x 1/2” Female NPT Threads.
- Pressure Rating::
- ● 1000 PSI (WOG).
- Handle Type::
- ● Lever Type Handle with a locking latch.
- Handle Stem:
- ● This 1/2" quarter turn valve is fitted with a stem that has a Blow Out Proof Design.
- To Change the Thread:
- ● Reduce the thread using a Bushing.
- ● Convert to Male Thread using a Hex Nipple or Close Nipple.
- ● For more options to convert the 1/2" Female NPT thread of this shut off valve, scroll down to “Upsell Products”
- Also Called:
- ● 1/2" Quarter Turn Shut Off Valve
- Material of Construction:
- ● 316 Stainless Steel.
- ● Scroll down to “Related Products” for Full Port options including 2-Piece and 3-Piece Options.
Specifications:
Size | 1/2" |
---|---|
Material | Stainless Steel 316 |
Handles | Stainless Steel 304 |
Part Number | BV050-SS-1 |
Temperature Rating | -4°F to 302°F |
Thread | 1/2" Female NP |
Working Pressure | 1000 PSI |
Seal | Teflon (PTFE) |
