3/4" 1-Piece Ball Valve

In stock
SKU
BV075-SS-1
More Information
Size3/4"
MaterialStainless Steel 316
HandlesStainless Steel 304
Part NumberBV075-SS-1
Temperature Rating-4°F to 302°F
Thread3/4" Female NPT
Working Pressure1000 PSI
SealTeflon (PTFE)
$12.80

3/4" Threaded, Reduced Port, One-Piece (1000 PSI)

CLICK HERE for All Sizes
CLICK HERE for Full Port



This robust 3/4 inch one piece ball valve with 3/4” female NPT thread on either end for easy connection. It is manufactured using high grade 304 stainless steel. It is a full port design, rated at 1000 PSI, and WOG ready (Water, Oil, Gas). It is Designed to control flow on a 3/4” pipe line with a simple “on” and “off” 90 degree turn of the handle. Handles can be locked in the open or closed position using a latch lock.



  • Product description:
  • ● 3/4” Female NPT Threaded, One Piece, Reduced Port Ball Valve
  • Uses:
  • Used to control flow with a "on/off" action.
  • Port (Bore):
  • ● Reduced Port.
  • Thread:
  • 3/4” Female NPT Threads x 3/4” Female NPT Threads.
  • Pressure Rating::
  • ● 1000 PSI (WOG).
  • Handle Type::
  • Lever Type Handle with a locking latch.
  • Handle Stem:
  • ● This 3/4" quarter turn valve is fitted with a stem that has a Blow Out Proof Design.
  • To Change the Thread:
  • Reduce the thread using a Bushing.
  • Convert to Male Thread using a Hex Nipple or Close Nipple.
  • For more options to convert the 3/4" Female NPT thread of this shut off valve, scroll down to “Upsell Products”
  • Also Called:
  • 3/4" Quarter Turn Shut Off Valve
  • Material of Construction:
  • ● 316 Stainless Steel.
  • ● Scroll down to “Related Products” for Full Port options including 2-Piece and 3-Piece Options.



Specifications:

More Information
Size3/4"
MaterialStainless Steel 316
HandlesStainless Steel 304
Part NumberBV075-SS-1
Temperature Rating-4°F to 302°F
Thread3/4" Female NPT
Working Pressure1000 PSI
SealTeflon (PTFE)
